MS-03 Series
Indoor & Outdoor Full-Scenario Display Coverage.
The MS-03 series offers versatile display solutions for both indoor and outdoor environments, ensuring full-scenario coverage. Engineered for high-performance applications, it delivers exceptional brightness, clarity, and reliability, whether used in bright outdoor settings or controlled indoor spaces.
Various Sizes
Modular design for cabinet sizes, meeting diverse installation needs.
High Precision
High-precision, high-strength die-casting cabinets ensure exquisite display quality.
High Refresh Rate
Refresh rate up to 3840Hz, delivering smooth, tear-free visuals.
Various Shapes
Supports 0-90° corner installations, suitable for various structural setups.
Wide Coverage Range
Pixel pitch range from P1.2 to P10, covering all indoor and outdoor application scenarios.
Specification
| Product | MS-12103 | MS-15103 | MS-18103 | MS-25103 | MS-30103 | MS-25003 | MS-30003 | MS-40003 | MS-50003 | MS-60003 | MS-80003 | MS-10003 |
| Pixel Pitch (mm) | 1.25 | 1.53 | 1.86 | 2.5 | 3.076 | 2.5 | 3.076 | 4 | 5 | 6 | 8 | 10 |
| Module size | 320 * 160 | 320 * 160 | 192 * 192 | 320 * 160 | ||||||||
| Cabinet Size | 640*480 | 960*960 | ||||||||||
| Cabinet Weight | 6.4kg | 18kg | ||||||||||
| IP Rating | IP41 | IP65 / IP54 | ||||||||||
| Brightness (Nits) | 600nits | ≥ 4500nits | ||||||||||
The product images and screen contents on this page are for illustrative purposes only. Actual product appearance (including but not limited to design, color, and dimensions) and screen display contents (including but not limited to backgrounds, UI, and illustrations) may slightly vary. Please refer to the actual product.
The MS-03 Series includes the following models: MS-12103、MS-15103、MS-18103 、MS-25103、MS-30103、MS-25003、MS-30003、MS-40003、MS-50003、MS-60003、MS-80003、MS-10003. The barcode encoding rule on the back of the product module is as follows: PXL8 MS-12103 DC250101XX-X 000X. Here, “PXL8” represents the factory identification and verification code, “MS-12103” indicates the product model, “DC250101XX-X” is the order number, and “000X” represents the module’s sequential code. (Note: “X” indicates a specific number.)
To provide the most accurate product details, specifications, and features, SkyFlex reserves the right to adjust and update textual descriptions, images, and other content on the webpage in real-time, ensuring consistency with the actual product’s performance, specifications, metrics, and components.
Due to real-time changes in product batches and production supply factors, modifications may occur without prior notice. We apologize for any inconvenience caused. For the latest updates, please refer to the official website.
